Infratech 1 Relay Home Management System Control Panel
Infratech 1 Relay Home Management System Control Panel
| The Infratech 1 Relay Home Management System Control Panel integrates your Infratech heating system directly into your smart home automation platform. Compatible with leading home management systems including Lutron, Crestron, Control 4, Savant, and other systems that accept a 0-10V DC signal, this panel provides seamless control of your heaters through your existing smart home interface. Program custom heating schedules, save preferred heat settings, create zone heating configurations, and control your heaters remotely via your home automation mobile app. Each relay handles up to 9,000 watts at 240V (8,000 watts at 208V), supporting all Infratech single and dual element heaters from 208V through 480V. The 1-relay configuration provides up to 9,000W of total heating capacity across up to 1 independent zone. The panel is UL 508 listed, NEMA 4 rated for weatherproof outdoor installation, and custom built to your specifications. Made in the USA with a 3-year manufacturer warranty. |
Key Features
- 1 relay - up to 9,000W total capacity at 240V (8,000W at 208V)
- Direct integration with Lutron, Crestron, Control 4, Savant, and compatible systems
- 0-10V DC signal interface for streamlined programming
- Remote control via your home automation mobile app
- Programmable heating schedules and saved heat settings
- Zone heating with independent 0-100% intensity per zone
- Compatible with all Infratech 208V-480V heaters (C, CD, W, WD, SL, Motif Series)
- NEMA 4 rated weatherproof enclosure
- Each relay handles up to 9,000W at 240V with up to 3 heaters per relay
- UL 508 Listed | Made in the USA | 3-year warranty
Compatibility & Configuration Guide
|
Which Home Automation Systems Are Compatible? The Home Management Panel works with any system that accepts a 0-10V DC signal input, including Lutron, Crestron, Control 4, Savant, and many other commercial and residential automation platforms. Your home automation integrator will program the heater controls through your system interface. How Many Relays Do I Need? Each relay is one zone. Heaters on the same relay are controlled together. For independent control of each heater, assign one relay per heater. Group matching-wattage heaters on a single relay (max 9,000W at 240V) for zone control. Home Management vs. Universal vs. Solid State: Choose Home Management if you have an existing Lutron, Crestron, Control 4, or similar system and want full integration. Choose Universal if you want flexible WiFi/Bluetooth with any 120V switch. Choose Solid State for straightforward commercial analog control with timer. What Is Not Included? The home automation system interface and programming are not included. You will need your home automation integrator to program the heater controls within your existing system. The panel provides the 0-10V DC signal connection points for your integrator. |
Manufacturer Downloads
- Infratech Control Systems Manual
- Infratech Heater Control Options Brochure
- Infratech Heater Comparison Chart
- Infratech Reference Manual
Warranty InformationInfratech warrants that this control product is designed and manufactured to be free from defects in materials and workmanship for a period of three (3) years from the original date of purchase. This warranty covers defects in electrical components under normal use. Professional installation by a licensed electrician is required. All custom control panels are built to specification and are final sale. |
Infratech 1 Relay Home Management System Control Panel | |
|---|---|
| Model Number | 30-4061 |
| Number of Relays | 1 |
| Maximum Wattage Per Relay | 9,000W at 240V / 8,000W at 208V |
| Maximum Heaters Per Relay | 3 |
| Total Panel Capacity (1 Relay) | 9,000W at 240V / 8,000W at 208V |
| Compatible Heaters | All Infratech 208V-480V (C, CD, W, WD, SL, Motif Series) |
| Compatible Systems | Lutron, Crestron, Control 4, Savant, and 0-10V DC compatible |
| Signal Interface | 0-10V DC |
| Zone Control | Up to 1 independent zone |
| Dimming | 0-100% variable intensity via home automation system |
| Remote Control | Via home automation mobile app |
| Enclosure Rating | NEMA 4 - Fully Weatherproof |
| Power Configuration | Single Phase or Three Phase (specify at order) |
| Voltage Compatibility | 208V, 240V, 277V, 480V |
| Certifications | UL 508 Listed |
| Warranty | 3-Year Manufacturer Warranty |
| Made In | USA |
$2,108.00
